A C Drive (20% to 40%) power saving

Get a Price/Quote

A C Drive (20% to 40%) power saving Specification

Surface Finish
Smooth / Industrial Grade

Capacity
Variable as per Motor rating

Noise Level
< 65 dB

Usage & Applications
Pumps, Fans, Compressors, HVAC, Conveyors, Industrial Machines

Shape
Rectangular

Motor Power
2 HP to 60 HP

Features
20% to 40% energy saving, User Friendly Interface, Overload Protection, Digital Display

Size
Multiple sizes available as per application

Drive Type
AC Variable Frequency Drive (VFD)

Product Type
A C Drive (20% to 40% Power Saving)

Material
Industrial Grade ABS and Metal Components

Technology
Variable Frequency Drive (VFD) Technology

Power Source
Electric

Power
Up to 60 kW (varies by model)

Surface Treatment
Powder Coated / Matt Finish

Dimension (L*W*H)
Approx. 350 mm x 225 mm x 195 mm

Color
Grey / Black

About A C Drive (20% to 40%) power saving

Servo Drive (40% to 80%) power saving

		HMV01.1E-W0030	HMV01.1E-W0075	HMV01.1E-W0120	HMV01.1R-W0018
Power
Input voltage	[V]	3 x AC 380...480 V
Tolerances	[%]	10 %
Frequency		50...60 Hz
Frequency tolerances	[Hz]	2 Hz
Continuous input mains current	[A]	51	125	-	26
Dependence of output on mains voltage	U_LN < 400 V	1 % power reduction per 4 V
Dependence of output on mains voltage	U_LN > 400 V	1 % power gain per 5 V			no power gain
DC bus
Continuous output with choke	[kW]	30	75	120	18
Max. output with choke	[kW]	45	112,5	180	45
Continuous output without choke	[kW]	18	45	72	-
Max. output without choke	[kW]	45	112,5	180	-
Output voltage	[V]	DC 435...710 V			DC 750 V
DC bus capacity	[mF]	1,41	3,76	5,64	0,705
DC bus voltage	[V] DC	Main voltage x 1,41			-
Brake chopper / resistor
Braking Energy Consumption	[kWs]	100	250	500	80
Continuous braking power	[kW]	1,5	2	2,5	0,4
Maximum braking power	[kW]	36	90	130	36
Control Voltage
Control Voltage	external	24V 5 %
Power consumption without control unit and motor brake	[W]	25	30	55	31
Protection
Category Total		IP20 (IEC529)
Degree of contamination		2 (EN50178)
EMC		EN61800-3
Cooling system		forced ventilated
Standards
Certification		EN61800-5-1 UL 508 C
Weight
Weight	[kg]	13,5	22	32	13,5
Ambient conditions
Ambient temp. operation	[C]	0 ... 40 C
Ambient temp. operation	Derating [C]	0 ... 55 C
Ambient temp. storage	[C]	-25...55 C
Relative humidity operation	[%]	5...95 %
Relative humidity storage	[%]	5...95 %
Installation height	[m]	1000
Installation height	[m] Derating	4000

Servo Drive (40% to 80%) power saving

		HMV01.1R-W0045	HMV01.1R-W0065	HMV01.1R-W0120	HMV02.1R-W0015
Power
Input voltage	[V]	3 x AC 380...480 V
Tolerances	[%]	10 %
Frequency		50...60 Hz
Frequency tolerances	[Hz]	2 Hz
Continuous input mains current	[A]	65	94	181	23
Dependence of output on mains voltage	U_LN < 400 V	1 % power reduction per 4 V
	U_LN > 400 V	no power gain
DC bus
Continuous output with choke	[kW]	45	65	120	15
Max. output with choke	[kW]	112	162	180	30
Output voltage	[V]	DC 750 V
DC bus capacity	[mF]	1,88	2,82	4,95	0,705
Brake chopper / resistor
Braking Energy Consumption	[kWs]	100	150	-	40
Continuous braking power	[kW]	0,4		-	0,3
Maximum braking power	[kW]	90	130	-	33
Control Voltage
Control Voltage	external	24V 5 %
Power consumption without control unit and motor brake	[W]	41	108	224	27
Protection
Category Total		IP20 (IEC529)
Degree of contamination		2 (EN50178)
EMC		EN61800-3
Cooling system		forced ventilated
Standards
Certification		EN61800-5-1 UL 508 C
Weight
Weight	[kg]	20	31	34,5	9,5
Ambient conditions
Ambient temp. operation	[C]	0 ... 40 C
	Derating [C]	0 ... 55 C
Ambient temp. storage	[C]	-25...55 C
Relative humidity operation	[%]	5...95 %
Relative humidity storage	[%]	5...95 %
Installation height	[m]	1000
	[m] Derating	4000

Electric Drives and Controls, Online version, as of 2010-03-29

Bosch Rexroth AG, subject to change

Energy Efficiency Meets Advanced Control

Achieve substantial energy reductions of 20% to 40% with this AC Variable Frequency Drive. Built for efficiency, it expertly controls motor speed using sensorless vector or V/F modes, adapting to load requirements and cutting needless energy expenditure. This makes the drive an excellent choice for businesses seeking to lower operational costs without compromising performance across pumps, fans, HVAC, and other applications.

Built for Industrial Demands

Engineered for the diverse needs of industrial environments, this drive combines rugged constructionindustrial-grade ABS and metalwith IP20 or IP21 protection. Forced air cooling and comprehensive overload, voltage, and short circuit features ensure reliable operation. Finished in grey or black and designed for wall or panel mounting, it integrates seamlessly into workflows while keeping noise below 65 dB.

Seamless Connectivity and Intuitive Operation

Benefit from hassle-free setup and monitoring with an intuitive digital LED display and easy-to-navigate controls. The drive is equipped with RS485/Modbus communication, allowing remote command and feedback to enhance process control and maintain efficiency. Its modular design supports flexible installation and multipurpose usage across various industries.

FAQs of A C Drive (20% to 40%) power saving:

Q: How does this AC Drive save 20% to 40% energy in industrial applications?

A: The AC Drive uses advanced VFD (Variable Frequency Drive) technology with sensorless vector and V/F control to adjust the speed of electric motors precisely according to load demands. This minimizes energy waste during partial load operation and helps achieve significant power savings, typically between 20% and 40%.

Q: What types of machines and systems can this AC Drive be installed on?

A: This AC Drive is suitable for pumps, fans, compressors, HVAC units, conveyors, and various other industrial machines. It supports motor power ratings from 2 HP to 60 HP, making it adaptable for a range of small to large-scale industrial applications.

Q: When should I opt for sensorless vector control versus V/F control?

A: Sensorless vector control offers superior speed and torque regulation, making it ideal for applications requiring high dynamic performance, such as conveyors and compressors. V/F control, on the other hand, is suitable for simpler, constant-torque applications like pumps and fans.

Q: Where can this AC Drive be mounted, and what are its enclosure ratings?

A: The drive can be mounted on either a wall or a panel, accommodating diverse installation sites. It is available with IP20 or IP21 enclosure ratings, offering protection against solid objects and limited ingress of moisture, suitable for indoor industrial environments.

Q: What process is involved in setting up the drive for remote communication and monitoring?

A: This drive features RS485/Modbus interfaces, making it straightforward to connect with control systems. After wiring the communication lines, simply configure the communication parameters on the drives digital interface. This facilitates remote monitoring, parameter adjustments, and process integration.

Q: How does overload and fault protection work in this drive?

A: The drive is designed with multiple protection features, including input over/under voltage, overcurrent, short circuit, phase loss, and overtemperature safeguards. These automated protections help prevent damage to both the drive and connected machinery, ensuring long-term reliability and safety during operation.

Q: What are the key benefits of using this AC Drive in my facility?

A: Implementing this drive results in reduced energy consumption, lower operational noise (below 65 dB), improved equipment lifespan due to smart control, and straightforward operation via a digital user interface. Its robust construction and moderate footprint make it ideal for new installations or retrofits in demanding industrial settings.
